1/2 x 1/2 x 1/2 Inch Neodymium Rare Earth Surplus Block Magnet N42 PN: ZB888

• Dimensions: 1/2" x 1/2" x 1/2" thick
• Tolerances: ±0.004" x ±0.004" x ±0.004"
• Material: NdFeB, Grade N42
• Plating/Coating: Ni-Cu-Ni (Nickel)
• Magnetization Direction: Thru Thickness
• Weight: 0.542 oz. (15.37 g)
• Pull Force, Case 1: 18.71 lbs
• Pull Force, Case 2: 21.64 lbs
• Surface Field: 5754 Gauss
• Max Operating Temp: 176ºF (80ºC)
• Brmax: 13,200 Gauss
• BHmax: 42 MGOe

These 1/2" cube magnets are just like our stock B888 magnets, but with poor plating.  Some of these magnets have splotches and imperfections in the plating, and just aren't good enough to be our stock B888 cubes.  Our mistake might be your gain.  If this difference doesn't matter to you, get these surplus cubes while they last!

Very strong cubes. These things can hold a lot of weight. Please use caution when handling. Two of these magnets or one magnet and anything metal could pinch you if you aren't careful. Very strong!! The cube shape makes them excellent for holding metal pieces for any metal working project.

	Pull Force, Case 1 vs. distance: Magnet to a Steel Plate.
	Pull Force, Case 2 vs. distance: Between 2 Steel Plates.
	Pull Force, Case 3 vs. distance: Magnet to Magnet.
	Pull Force, Case 4 vs. distance: Magnet to Magnet Repulsion.
	Click this link for a depiction of the magnetic field.
	View B-H curves for this magnet.
